Chrysler Town & Country | 2001-2007

This guide covers the fourth-generation Chrysler Town & Country (2000–2007), also marketed as the Chrysler Voyager, Chrysler Grand Voyager (LWB), Chrysler Caravan (Brazil), Chrysler Grand Caravan (LWB, Brazil), and Chrysler Ram Van (Netherlands). Here you’ll find fuse box diagrams for Chrysler Town & Country 2001, 2002, 2003, 2004, 2005, 2006 and 2007, along with information about the locations of the fuse panels inside the vehicle and the functions of each fuse (fuse layout).

NEED A REPLACEMENT?
Looking for the right fuse or relay?
Search common fuse types, fuse kits and relay options for your vehicle.
Find Fuses & Relays

Fuse box location

An Integrated Power Module (IPM) located in the engine compartment near the battery.

The location of the fuses in the engine compartment: Chrysler Town & Country / Voyager

Fuse box diagram

Fuse Data
Full access is available to registered users — log in or register.
Log in or register

Integrated Power Module — Fuses & Relays (2007 Town & Country)
No. Amp Type Description
F430AFMX/JCaseFront Wipers
F940AFMX/JCaseAnti-Lock Brake System (ABS) Pump
F1040AFMX/JCaseFront Blower
F1340AFMX/JCaseElectronic Back Light (EBL)
F1940AFMX/JCaseBody Control Module (BCM) Feed 1
F2030AFMX/JCaseCentral Amplifier
F2230AFMX/JCaseSeats
F2740AFMX/JCaseRadiator Fan
F2840AFMX/JCasePower Windows
F3040AFMX/JCaseHeadlight Washers [Export Only]
F3140AFMX/JCasePower Sliding Door
F3240AFMX/JCasePower Liftgate
F120AMINIFog Lights
F215AMINILeft Park/Tail Light
F315AMINIRight Park/Tail Light
F520AMINIRDO/IP Ignition
F620AMINI12 Volt Out Ignition or Battery
F820AMINIHorn
F1120AMINIEWD/ Rear Wiper
F1225AMINIRear Blower
F1420AMINIIgnition Off Draw (IOD)
F1520AMINIElectronic Automatic Transaxle (EATX) Battery
F1525AMINIASD
F1720AMINIFuel Pump
F1815AMINIA/C Clutch
F2125AMINIAnti-Lock Brake System (ABS) Module
F2310AMINIIgnition Switch
F2420AMINIHazard
F2620AMINIStop Lamp
F3315AMINIFront/Rear Washer
F3320AMINISpare (IOD)
R1—RelaySPARE1
R2—RelaySPARE2
R3—RelayPARK LAMP RELAY
R4—RelayHORN RELAY
R5—RelayFRONT FOG LAMP
R6—RelayA/C COMPRESSOR CLUTCH RELAY
R7—RelayREAR WINDOW DEFOGGER RELAY
R8—RelayREAR BLOWER MOTOR RELAY
R9—RelayFUEL PUMP RELAY
R10—RelayACCESSORY RELAY
R11—RelayFRONT BLOWER MOTOR RELAY
R12—RelayTRANSMISSION SAFETY SHUTDOWN RELAY
R13—RelayNAME BRAND SPEAKER RELAY
R14—RelayFRONT WIPER HIGHLOW RELAY
R15—RelaySTARTER MOTOR RELAY
R16—RelayAUTOMATIC SHUTDOWN RELAY
R17—RelayFRONT WIPER ON OFF RELAY
Source: 2007 Chrysler Town and Country OWNER’S MANUAL
Note: FMX/JCase entries are cartridge fuses, MINI entries are mini-blade fuses, and the rest are relays located in the integrated power module.
