Dodge Neon (2000-2005) Fuse Box Diagrams and Locations

Dodge Neon (1994-1999)

Explore Dodge Neon fuse box diagrams in this quick guide that helps you identify the wiring layout for the final years of the second generation. Here we focus on the second-generation Dodge Neon (2000–2005) and provide fuse information for 2000, 2001, 2002, 2003, 2004 and 2005, including the location of the fuse panels and the assignment of each fuse, giving you a clear reference for troubleshooting and maintenance.

What’s Included

Engine compartment

Fuse box location

A Power Distribution Center (PDC) is located in the engine compartment, next to the battery.

The location of the fuses in the engine compartment: Dodge Neon (2000-2005)

A label identifying the components and circuits is located on the underside of the cover.

Fuse box diagram

Maxi fuses

Assignment of maxi fuses in the Power Distribution center

Fuse Data

Full access is available to registered users — log in or register.

No.	Amp rating	Description
1	—	—
2	—	—
3	40 Amp/ Green	Headlamps
4	40 Amp/ Green	Ignition Run
5	30 Amp/Pink	ABS Solenoid
6	30 Amp/Pink	Radiator Fan
7	Spare
8	40 Amp/ Green	ABS Pump
9	30 Amp/Pink	Starter
10	40 Amp/ Green	Electric Back Light (EBL)

Mini fuses

Assignment of mini fuses in the Power Distribution center

Fuse Data

Full access is available to registered users — log in or register.

No.	Description	Amp rating
11	Spare
12	Spare
13	20 Amp/ Yellow	IOD/Int Lighting/Radio
14	20 Amp/ Yellow	Power Outlet
15	15 Amp/Blue	Hazard Flasher
16	15 Amp/Blue	MTV
17	20 Amp/ Yellow	Electronic Automatic Transaxle (EATX)
18	10 Amp/Red	Horn
19	Spare
20	20 Amp/ Yellow	Fog Lamp (Export Only)
21	20 Amp/ Yellow	ASD/Fuel Pump
22	10 Amp/Red	A/C Clutch
23	15 Amp/Blue	Stop Lamps

Passenger compartment

Fuse box location

The fuse access panel is behind the end cover at the left side of the instrument panel.
To remove the panel, pull it out, as shown. A diagram identifying the components and circuits is located on the inside of the cover.

The location of the fuses in the passenger compartment: Dodge Neon (2000-2005)

Fuse box diagram

Assignment of the interior fuses

Fuse Data

Full access is available to registered users — log in or register.

№	Amp/Color	Items Fused
1	10 Amp/Red	Power Mirror/ Multifunction
2	20 Amp/ Yellow	Wiper Switch/Motor
3	20 Amp/ Yellow	Radio/Power Sunroof
4	15 Amp/Blue	Interior Lighting
5	10 Amp/Red	Airbag Run Only
6	20 Amp/ Yellow	HVAC Blower
7	10 Amp/Red	Backup Switch/EBL/ Temp/Comp
8	15 Amp/Blue	High Headlamp
9	10 Amp/Red	Airbag Run-Start
10	15 Amp/Blue	ABS Engine Run Start
11	10 Amp/Red	ARKEM Run Start
12	10 Amp/Red	Ignition Off/Run/ Start
13	20 Amp/ Yellow	Power Seat Height Adjust
14	20 Amp/ Yellow	ARKEM Door Locks
15	15 Amp/Blue	Exterior Lighting
16	25 Amp/ Natural	Headlamp
17	10 Amp/Red	Lt Low Beam Headlamp/ Headlamp Level Switch (Bux Only)
18	10 Amp/Red	Rt Low Beam Headlamp/ Headlamp Level Motor
19	10 Amp/Red	Fog lamps
20	Spare

FAQ

What fuse controls the cigar lighter/power outlet in the Dodge Neon?

The cigar lighter (power outlet) in the Dodge Neon is protected by fuse №14 in the Power Distribution Center.
