Ford Territory | 2011-2016 | Fuse Box Location and Diagram

The Ford Territory (SZ), a mid-size crossover SUV, was produced from 2011 to 2016. Known for its spacious interior, versatile design, and reliability, the SZ model became a popular choice for families and businesses alike during its production years.

In this article, you will find fuse box diagrams for Ford Territory models produced between 2011 and 2016, covering years 2011, 2012, 2013, 2014, 2015, and 2016. These diagrams provide critical information about the fuse layout and relay assignments, helping owners and technicians effectively maintain and troubleshoot the vehicle’s electrical systems.

What’s Included:

Fuse Box Diagrams: Clear, detailed visuals for quick identification of fuses and relays.
Fuse Panel Locations: Instructions on where to locate the fuse panels inside the vehicle.
Fuse Assignments: Comprehensive descriptions of the function of each fuse and relay for accurate diagnostics and repairs.

Whether you’re addressing an electrical problem, replacing a blown fuse, or performing regular maintenance, this guide is an essential resource for Ford Territory (SZ) owners and technicians. It ensures your vehicle’s electrical systems remain functional and reliable.

Keep your Ford Territory (2011–2016) in peak condition with this detailed fuse box guide!

The cigar lighter (power outlet) fuses in the Ford Territory are fuse No.13 and fuse No.15, located in the Instrument Panel Fuse Box.

What’s Included

Passenger compartment fuse box

Fuse box location

It is located behind the panel on the driver’s side.

The location of the fuses in the passenger compartment: Ford Territory (2011-2016)

Fuse box diagram

Assignment of the fuses and relays in the Passenger compartment

№	Amps	Colour	Circuits Protected	Type
1	10	Red	Turn Signal Switch	Ignition
2	15	Blue	Coil Driver (Petrol Engine)	Ignition
3	7.5	Brown	Airbag	Ignition
4	15	Blue	Reverse Lights, Park Aid	Ignition
5	10	Red	ABS/DSC	Ignition
6	5	Tan	HIM	Ignition
7	15	Blue	Stop Lights, (PCM)	Ignition
8	10	Red	EPAS	Ignition
9	15	Blue	Transmission, AWD (Diesel Engine)	Ignition
10	20	Yellow	Washer Pump, Wiper	Accessory
11	15	Blue	Wiper Rear	Accessory
12	–	–	Not Used	–
13	20	Yellow	Power Outlet 2	Accessory
14	10	Red	Mobile Phone	Accessory
15	20	Yellow	Power Outlet 1	Accessory
16	20	Yellow	Amplifier	Battery
17	15	Blue	Turn Signal / Hazard Lights	Battery
18	20	Yellow	Transmission, ,AWD (Diesel Engine)	Battery
19	7.5	Brown	Power Mirrors, Rear Demister Relay, Electrochromatic Mirror	Accessory
20	10	Red	Body Control Module (BEM), Interior Command Centre	Accessory
21	7.5	Brown	Mobile Phone/DVD	Battery
22	20	Yellow	Door Locks	Battery
23	15	Blue	Tail/Park Lights, Cluster, Interior Command Centre (DVD Fuse 41) (if equipped)	Battery – Tail Relay
24	5	Tan	Body Control Module (BEM)/SDLC	Battery
25	15	Blue	Interior Lights, Antenna, Solar Sensor, Gearshift (Sports Sequential), Diagnostic Connector, DVD, Rain Sensor	Battery / Battery Saver
26	30	Green	Trailer	Battery
27	10	Red	HIM	Battery
28	15	Blue	Interior Command Centre, Display	Battery
29	10	Red	Instrument Cluster, Body Control Module (BEM),	Ignition
30	15	Blue	Injectors (Petrol Engine)	Ignition
31	30	Pink	Front Power Windows	Battery, BCM/ BEM Switched Window Relay
32	30	Pink	Rear Power Windows
33	30	Pink	Power Seats	Battery
34	–	–	Not Used	–
35	–	–	Not Used	–
36	–	–	Not Used	–
37	–	–	Not Used	–
38	–	–	Not Used	–
39	–	–	Not Used	–

			Additional Fuses (located next to DVD player)
40	10 / 5	Red / Tan	DVD (Accessory Input), (Lamp Input)	Battery Saver
41	5	Tan	DVD (Illumination Level)	Light Switch

Relays
R1	–	White	Ignition	Ignition
R2	–	White	Power Windows	BCM/BEM Switched
R3	–	White	Accessory	Accessory
R4	–	Black	Tail Lights	Light Switch

Engine compartment fuse box

Fuse box location

The location of the fuses in the engine compartment: Ford Territory (2011-2016)

Fuse box diagram

Petrol

Diesel

Assignment of the fuses and relays in the Engine compartment

№	Amps	Colour	Circuits Protected
F1	200	Black-Integrated Fuse Link	Main
F2	50	Black-Integrated Fuse Link	Batt 1
F3	50	Black-Integrated Fuse Link	Batt 2
F4	40	Black-Integrated Fuse Link	Starter
F5	50	Black-Integrated Fuse Link	Eng
F6	60	Black-Integrated Fuse Link	Ignition
F7	40	Black-Integrated Fuse Link	Backlight (Demister)
F8	60	Yellow-Midi Fuse	Glow Plugs 1 (Diesel)
F9	30	Orange-Midi Fuse	Glow Plugs 2 (Diesel)
F10	80	White-Midi Fuse	Cooling Fan (Diesel)
F11	100	Blue-Midi Fuse	Electric Power Assist Steering (EPAS)
F12	30	Green	Petrol: EEC (PCM) Canister Purge, IMCC, VCT, Fuel Relay Coil Diesel: VPWR1 (Fuel/WAC Relay Coil, ECM)
F13	20 / 15	Yellow / Blue	Petrol: Hego (20A) Diesel: VPWR2 (MAF) (15A)
F14	15	Blue	VPWR3 (PCV, VCV) (Diesel)
F15	15	Blue	Air-Conditioning Compressor
F16	5	Tan	EEC (PCM/ECM) KAP
F17	25	Natural	Wiper Front
F18	–	–	–
18	30	Pink	Glow Plugs 3 (Diesel)
F19	25	Natural	Headlamp-Low Relay Output to F29 L and F28 R Fuses
19	30	Pink	Glow Plugs 4 (Diesel)
F20	10	Red	Cluster
F21	15	Blue	Horn
F22	30	Green	Fuel
F23	20	Yellow	Fog Lamp
F24	20	Yellow	Ignition Switch
F25	20	Yellow	Headlamp-High-Right
F26	20	Yellow	Headlamp-High-Left
F27	15	Blue	VPWR4 (Water in Fuel Sensor, Glow Plug Relay Coil) (Diesel)
F28	15	Blue	Headlamp-Low-Right (Projector Lamp)
F29	15	Blue	Headlamp-Low-Left (Projector Lamp)
F30	40	Green	Fan 1 (Petrol)
F31	30	Pink	Batt 3
F32	40	Green	Blower Fan-Climate Control
F33	30	Pink	ABS2 DSC2 (DSC VR)
F34	40	Green	ABS1 DSC1 (DSC VR)
F35	–	–	–
F36	40	Green	Accessory

Relays
1	–	Black	Low Beam (when left high on) (Diesel)
2	–	Black	Petrol: PCM Diesel: Low Beam (when right high on)
3	–	White	Starter
4	–	White	Backlite (Demister)
5	–	–	–
6	–	Black	Fuel
7	–	Black	Horn
9	–	Black	WAC (Air-Conditioning Compressor)
10	–	White	Petrol: Fan 3 Diesel: ECM EEC
11	–	White	Fan 1 (Petrol)
12	–	White	Headlamp (Low)
13	–	White	Headlamp (High)
14	–	Black	Reverse
16	–	Black	Fog
18	–	Black	Headlamp Low Beam (when right high on) (Petrol)
19	–	Black	Headlamp Low Beam (when left high on) (Petrol)
20	–	Black (High Current)	Glow Plug (Diesel)
21	–	Black (High Current)	Glow Plug (Diesel)

Diode
15	–	Black	EEC (PCM-Petrol) (ECM-Diesel)
17	–	Black	Starter

Resistor
8	–	Green	Starter
