The first-generation Volvo V60, before its facelift, was produced from 2010 to 2014. Known for combining Scandinavian design, safety, and performance, the early V60 models offered a dynamic driving experience while providing the practicality of a family estate.
In this article, you will find fuse box diagrams for the Volvo V60, covering model years 2010, 2011, 2012, 2013 and 2014. These diagrams are essential for identifying and troubleshooting issues related to fuses and relays within the vehicle.
What’s Included:
Fuse Box Diagrams – Detailed illustrations showing the layout of fuses and relays.
Fuse Panel Locations – Guidance on where to find the fuse panels inside the car (e.g., engine bay, dashboard, luggage compartment).
Fuse Assignments – Complete breakdowns of what each fuse and relay controls (such as wipers, headlights, infotainment, HVAC), making repairs more accurate.
Whether you’re diagnosing an electrical issue or replacing a blown fuse, this guide will help you effectively service your Volvo V60 (2010–2014).
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox (For cars with the Start/Stop function this fuse location is empty)
50
2
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox
50
3
Primary fuse for central electrical unit in cargo area (For cars with the Start/Stop function this fuse location is empty)
60
4
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glove-box (For cars with the Start/Stop function this fuse location is empty)
60
5
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glove-box (For cars with the Start/Stop function this fuse location is empty)
60
6
7
PTC element air preheater (For cars with the Start/Stop function this fuse location is empty)
100
8
Headlamp washers (option)
20
9
Windscreen wipers
30
10
Parking heater (option)
25
11
Ventilation fan (For cars with the Start/Stop function this fuse location is empty)
40
12
–
–
13
ABS pump
40
14
ABS valves
20
15
16
Headlamp levelling (Xenon, Active Xenon) (option)
10
17
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox
20
18
ABS
5
19
Speed related power steering (option)
5
20
Engine control module, Transmission control module, Airbags
10
21
Heated washer nozzles (option)
10
22
Relay coil, relay, vacuum pump (5-cyl. petrol and 2.0T)
5
23
Headlamp control
5
24
25
26
27
Internal relay coils
5
28
Auxiliary lamps (option)
20
29
Horn
15
30
Relay coil, main relay, engine management system; Engine control module (5, 6-cyl. petrol)
10
31
Transmission control module
15
32
Compressor A/C
15
33
Relay coil, relay, compressor A/C; Relay coils in central electrical unit in engine compartment cold zone Start/ Stop
5
34
Actuator solenoid, starter motor (For cars with the Start/Stop function this fuse location is empty)
30
35
Ignition coils (4-cyl. petrol), Glow control module (diesel)
10
35
Ignition coils (5, 6-cyl. petrol)
20
36
Engine control module (petrol)
10
36
Engine control module (diesel)
15
37
Valves (1.6 I petrol) Mass air flow sensor (DRIVe), Control valve, fuel flow (DRIVe)
10
37
Mass air flow sensor (5-cyl. diesel), Control valves (5-cyl. diesel), Injectors (5, 6-cyl. petrol), Engine control module (6-cyl.)
15
38
Engine valves, Engine control module (6-cyl.) Solenoids, cam profile (6- cyl.) Actuator motors, intake manifold (6-cyl.) Mass air flow sensor (4- cyl. 2.0 l petrol); Coolant pump (DRIVe)
10
39
Lambda-sond (4-cyl. petrol, 5-cyl. diesel), Control module, radiator roller cover (D3 manual) Control module, radiator roller cover (DRIVe)
Fuses 1-7 and 42-44 are of the “Midi Fuse” type and must only be replaced by a workshop. Fuses 8-15 and 34 are of the “JCASE” type and should be replaced by a workshop. Fuses 16-33 and 35-41 are of the “Mini Fuse” type.
Under the glove compartment (Fuse box A)
Assignment of fuses under the glove compartment (Fuse box A – 2010, 2011)
Fuse Data
Full access is available to registered users — log in or register.
Main fuse for central electrical unit in the engine compartment
175
A2
Main fuse for central electronic module (CEM) with fuse box B under the glovebox, central electrical unit in passenger compartment with fuse box A under the glovebox, central electrical unit in cargo area
175
1
PTC element air preheater (option)
100
2
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox
50
3
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glovebox
60
4
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glovebox
60
5
Primary fuse for central electrical unit in cargo area
60
6
Ventilation fan
40
7
8
9
Actuator solenoid, starter motor
30
10
Internal diode
50
11
Support battery
70
12
CEM
5
Fuses A1 and A2 are of the “MEGA Fuse” type and must only be replaced by a workshop. Fuses 1-11 are of the “Midi Fuse” type and must only be replaced by a workshop. Fuse 12 is of the “Mini Fuse” type.
2012
Engine compartment
Assignment of fuses in the engine compartment (2012)
Fuse Data
Full access is available to registered users — log in or register.
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox (For cars with the Start/Stop function this fuse location is empty)
50
2
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox
50
3
Primary fuse for central electrical unit in cargo area (For cars with the Start/Stop function this fuse location is empty)
60
4
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glove-box (For cars with the Start/Stop function this fuse location is empty)
60
5
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glove-box (For cars with the Start/Stop function this fuse location is empty)
60
6
7
PTC element air preheater (For cars with the Start/Stop function this fuse location is empty)
100
8
Headlamp washers (option)
20
9
Windscreen wipers
30
10
Parking heater (option)
25
11
Ventilation fan (For cars with the Start/Stop function this fuse location is empty)
40
12
–
–
13
ABS pump
40
14
ABS valves
20
15
16
Headlamp levelling (Xenon, Active Xenon) (option)
10
17
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox
20
18
ABS
5
19
Speed related power steering (option)
5
20
Engine control module, Transmission control module, Airbags
10
21
Heated washer nozzles (option)
10
22
Relay coil, relay, vacuum pump (5-cyl. petrol and 2.0T)
5
23
Headlamp control
5
24
25
26
27
Internal relay coils
5
28
Auxiliary lamps (option)
20
29
Horn
15
30
Relay coil, main relay, engine management system; Engine control module (5, 6-cyl. petrol)
Relay coil, relay, compressor A/ C (not 5-cyl. diesel), Relay coil, relay, coolant pump (5-cyl. diesel Start/Stop); Relay coils in central electrical unit in engine compartment cold zone Start/Stop
5
34
Actuator solenoid, starter motor (For cars with the Start/Stop function this fuse location is empty)
30
35
Ignition coils (4-cyl. petrol), Glow control module (diesel)
10
35
Ignition coils (5, 6-cyl. petrol)
20
36
Engine control module (petrol)
10
36
Engine control module (diesel)
15
37
Valves (1.6 I petrol) Mass air flow sensor (DRIVe), Control valve, fuel flow (DRIVe)
10
37
Mass air flow sensor (5-cyl. diesel), Control valves (5-cyl. diesel), Injectors (5, 6-cyl. petrol), Engine control module (6-cyl.)
15
38
Compressor A/C (5, 6-cyl.), Engine valves, Engine control module (6-cyl.) Solenoids (6-cyl. without turbo), Actuator motors, intake manifold (6-cyl. without turbo), Mass air flow sensor (4- cyl. 2.0 l petrol), Oil level sensor (5-cyl. diesel); Coolant pump (D4162T)
10
39
Lambda-sond (4-cyl. petrol, 5-cyl. diesel), Control module, radiator roller cover (D3 manual) Control module, radiator roller cover (DRIVe)
10
39
Lambda-sonds (4-cyl. petrol), Lambda-sond (diesel), Control module, radiator roller cover (manual 5-cyl. 2.0 l diesel)
Fuses 1-7 and 42-44 are of the “Midi Fuse” type and must only be replaced by a workshop. Fuses 8-15 and 34 are of the “JCASE” type and should be replaced by a workshop. Fuses 16-33 and 35-41 are of the “Mini Fuse” type.
Under the glove compartment (Fuse box A)
Assignment of fuses under the glove compartment (Fuse box A – 2012)
Fuse Data
Full access is available to registered users — log in or register.
Main fuse for central electrical unit in the engine compartment
175
A2
Main fuse for central electronic module (CEM) with fuse box B under the glovebox, central electrical unit in passenger compartment with fuse box A under the glovebox, central electrical unit in cargo area
175
1
PTC element air preheater (option)
100
2
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox
50
3
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glovebox
60
4
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glovebox
60
5
Primary fuse for central electrical unit in cargo area
60
6
Ventilation fan
40
7
8
9
Actuator solenoid, starter motor
30
10
Internal diode
50
11
Support battery
70
12
CEM
5
Fuses A1 and A2 are of the “MEGA Fuse” type and must only be replaced by a workshop. Fuses 1-11 are of the “Midi Fuse” type and must only be replaced by a workshop. Fuse 12 is of the “Mini Fuse” type.
2013
Engine compartment
Assignment of fuses in the engine compartment (2013)
Fuse Data
Full access is available to registered users — log in or register.
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox (For cars with the Start/Stop function this fuse location is empty)
50
2
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox
50
3
Primary fuse for central electrical unit in cargo area (For cars with the Start/Stop function this fuse location is empty)
60
4
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glove-box (For cars with the Start/Stop function this fuse location is empty)
60
5
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glove-box (For cars with the Start/Stop function this fuse location is empty)
60
6
7
PTC element air preheater (For cars with the Start/Stop function this fuse location is empty)
100
8
Headlamp washers (option)
20
9
Windscreen wipers
30
10
Parking heater (option)
25
11
Ventilation fan (For cars with the Start/Stop function this fuse location is empty)
40
12
–
–
13
ABS pump
40
14
ABS valves
20
15
16
Headlamp levelling (Xenon, Active Xenon) (option)
10
17
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox
20
18
ABS
5
19
Speed related power steering (option)
5
20
Engine control module, Transmission control module, Airbags
10
21
Heated washer nozzles (option)
10
22
23
Headlamp control
5
24
25
26
27
Internal relay coils
5
28
Auxiliary lamps (option)
20
29
Horn
15
30
Relay coil in main relay for engine management system; Engine control module (5, 6-cyl. petrol)
Relay coil in relay for solenoid clutch A/C (not 5-cyl. diesel); Relay coil in relay for coolant pump (5-cyl. diesel Start/Stop); Relay coils in central electrical unit in engine compartment cold zone (Start/Stop)
5
34
Start relay (For cars with the Start/Stop function this fuse location is empty)
30
35
Ignition coils (4-cyl. petrol), Glow control module (diesel)
10
35
Ignition coils (5, 6-cyl. petrol)
20
36
Engine control module (petrol)
10
36
Engine control module (diesel)
15
37
Valves (1.6 l petrol); Mass air flow sensor (1.6 l petrol); Mass air flow sensor (D4162T); Control valve, fuel flow (D4162T)
10
37
Mass air flow sensor (5-cyl. diesel, 6-cyl.); Control valves (5- cyl. diesel); Injectors (5, 6-cyl. petrol); Engine control module (5-cyl. petrol, 6-cyl.)
15
38
Solenoid clutch A/C (5, 6-cyl.); Valves, Engine control module (6-cyl.) Solenoids (6-cyl. without turbo); Actuator motors, intake manifold (6-cyl. without turbo); Mass air flow sensor (4-cyl. 2.0 l petrol, 5-cyl. petrol); Oil level sensor (5-cyl. diesel); Coolant pump (D4162T)
10
39
Lambda-sond (4-cyl. petrol, 5-cyl. diesel), Control module, radiator roller cover (D3 manual) Control module, radiator roller cover (DRIVe)
10
39
Lambda-sonds (4-cyl. petrol), Lambda-sond (diesel), Control module, radiator roller cover (manual 5-cyl. 2.0 l diesel)
Fuses 1-7 and 42-44 are of the “Midi Fuse” type and must only be replaced by a workshop. Fuses 8-15 and 34 are of the “JCASE” type and should be replaced by a workshop. Fuses 16-33 and 35-41 are of the “Mini Fuse” type.
Under the glove compartment (Fuse box A)
Assignment of fuses under the glove compartment (Fuse box A – 2013)
Fuse Data
Full access is available to registered users — log in or register.
Main fuse for central electrical unit in the engine compartment
175
A2
Main fuse for central electronic module (CEM) with fuse box B under the glovebox, central electrical unit in passenger compartment with fuse box A under the glovebox, central electrical unit in cargo area
175
1
PTC element air preheater (option)
100
2
Primary fuse for the central electronic module (CEM) with fuse box B under the glovebox
50
3
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glovebox
60
4
Primary fuse for central electrical unit in passenger compartment with fuse box A under the glovebox
60
5
Primary fuse for central electrical unit in cargo area
60
6
Ventilation fan
40
7
8
9
Start relay
30
10
Internal diode
50
11
Support battery
70
12
Central electronic module (CEM) – reference voltage support battery; Charging point support battery
15
Fuses A1 and A2 are of the “MEGA Fuse” type and must only be replaced by a workshop. Fuses 1-11 are of the “Midi Fuse” type and must only be replaced by a workshop. Fuse 12 is of the “Mini Fuse” type.
2014
Engine compartment
Assignment of fuses in the engine compartment (2014)
Fuse Data
Full access is available to registered users — log in or register.
Primary fuse for the central electronic module (CEM) under the glovebox (For cars with the Start/Stop function this fuse location is empty)
50
2
Primary fuse for the central electronic module (CEM) under the glovebox
50
3
Primary fuse for central electrical unit in cargo area (For cars with the Start/Stop function this fuse location is empty)
60
4
Primary fuse for relay/fuse box under the glovebox (For cars with the Start/Stop function this fuse location is empty)
60
5
Primary fuse for relay/fuse box under the glovebox (For cars with the Start/Stop function this fuse location is empty)
60
6
7
Electric additional heater (option) (For cars with the Start/Stop function this fuse location is empty)
100
8
Heated windscreen (option), left-hand side
40
9
Windscreen wipers
30
10
Parking heater (option)
25
11
Ventilation fan (For cars with the Start/Stop function this fuse location is empty)
40
12
Heated windscreen (option), right-hand side
40
13
ABS pump
40
14
ABS valves
20
15
Headlamp washer (option)
20
16
Headlamp levelling (option); Active Xenon headlamps – ABL (option)
10
17
Primary fuse for the central electronic module (CEM) under the glovebox
20
18
ABS
5
19
Adjustable steering force (option)
5
20
Engine control module; Transmission control module; Airbags
10
21
Heated washer nozzles (option)
10
22
–
–
23
Light switches
5
24
25
26
27
Relay coils
5
28
Auxiliary lamps (option)
20
29
Horn
15
30
Relay coil in main relay for engine management system; Engine control module (4-cyl. 2.0 l (Does not apply to the B4204T7 engine), 5, 6-cyl.)
10
31
Transmission control module
15
32
Solenoid clutch A/C (not 4-cyl. 2.0 l (However, does apply to the B4204T7 engine), not 5-cyl. diesel); Supporting coolant pump (4-cyl. 2.0 1 diesel)
15
33
Relay coil in relay for solenoid clutch A/C (not 5-cyl. diesel); Relay coil in relay for coolant pump (1.6 I petrol Start/Stop); Relay coils in central electrical unit in engine compartment cold zone (Start/Stop)
5
34
Start relay (For cars with the Start/Stop function this fuse location is empty)
30
35
Ignition coils (1.6 l petrol, engine B4204T7); Glow control module (5-cyl. diesel)
10
35
Engine control module (4-cyl. 2.0 l (Does not apply to the B4204T7 engine)); Ignition coils (5, 6-cyl. petrol); Capacitor (6-cyl.)
20
36
Engine control module (petrol except 4-cyl. 2.0 l (However, does apply to the B4204T7 engine))
10
36
Engine control module (1.6 l diesel, 5-cyl. diesel)
15
36
Engine control module (4-cyl. 2.0 l (Does not apply to the B4204T7 engine))
20
37
Valves (1.6 l petrol); mass air flow sensor (1.6 l, 4-cyl. 2.0 l (Does not apply to the B4204T7 engine)); Thermostat (4-cyl. 2.0 l petrol (Does not apply to the B4204T7 engine)); EVAP valve (4-cyl. 2.0 l petrol (Does not apply to the B4204T7 engine)); Cooling valve for climate control system (4-cyl. 2.0 l diesel); Cooling pump for EGR (4-cyl. 2.0 l diesel); Mass air flow sensor (engine D4162T); Control valve, fuel flow (engine D4162T)
10
37
Mass air flow sensor (5-cyl. diesel, 6-cyl.); Control valves (5-cyl. diesel); Injectors (5, 6- cyl. petrol); Engine control module (5-cyl. petrol, 6-cyl.)
15
38
Solenoid clutch A/C (5, 6-cyl.); Valves (1.6 I, engine B4204T7; 5-cyl., 6-cyl.); Engine control module (6-cyl.); Solenoids (6-cyl. without turbo); Actuator motors, intake manifold (6-cyl. without turbo); Mass air flow sensor (engine B4204T7; 5-cyl. petrol); Oil level sensor (5-cyl. diesel)
10
38
Valves (4-cyl. 2.0 l (Does not apply to the B4204T7 engine)); Oil pump (4-cyl. 2.0 I petrol (Does not apply to the B4204T7 engine)); Lambda-sond, centre (4-cyl. 2.0 I petrol (Does not apply to the B4204T7 engine)); Lambda-sond, rear (4-cyl. 2.0 I diesel)
15
39
Lambda-sonds (1.6 l petrol, engine B4204T7); Lambdasond (5-cyl. diesel); Control module, radiator roller cover (1.6 l diesel, 5-cyl. diesel)
10
39
Lambda-sond, front (4-cyl. 2.0 l (Does not apply to the B4204T7 engine)); Lambda-sond, rear (4- cyl. 2.0 l petrol (Does not apply to the B4204T7 engine)); EVAP valve (5, 6-cyl. petrol); Lambdasonds (5, 6-cyl. petrol)
15
40
Coolant pump (1.6 I petrol Start/Stop); Crankcase ventilation heater (5-cyl. petrol); Oil pump automatic gearbox(5-cyl. petrol Start/Stop)
10
40
Ignition coils (4-cyl. 2.0 I petrol (Does not apply to the B4204T7 engine))
15
40
Diesel filter heater
20
41
Control module, radiator roller cover (5-cyl. petrol)
Solenoid clutch A/C (4-cyl. 2.0 l (Does not apply to the B4204T7 engine)); Glow control module (4-cyl. 2.0 1 diesel); Oil pump (4-cyl. 2.0 1 diesel)
15
42
Coolant pump (4-cyl. 2.0 1 petrol (Does not apply to the B4204T7 engine))
50
42
Glow plugs (diesel)
70
43
Cooling fan (1.6 I, 4-cyl. 2.0 I petrol, 5-cyl. petrol)
60
43
Cooling fan (6-cyl., 4-cyl. 2.0 I diesel, 5-cyl. diesel)
80
44
Power steering
100
Fuses 1-7 and 42-44 are of the “Midi Fuse” type and must only be replaced by a workshop. Fuses 8-15 and 34 are of the “JCASE” type and should be replaced by a workshop. Fuses 16-33 and 35-41 are of the “Mini Fuse” type.
Under the glove compartment (Fuse box A)
Assignment of fuses under the glove compartment (Fuse box A – 2014)
Fuse Data
Full access is available to registered users — log in or register.
Main fuse for central electrical unit in the engine compartment
175
A2
Main fuse for central electronic module (CEM) under the glovebox, relay/fuse box under the glovebox, central electrical unit in cargo area
175
1
Electric additional heater (option)
100
2
Primary fuse for the central electronic module (CEM) under the glovebox
50
3
Primary fuse for relay/fuse box under the glovebox
60
4
Primary fuse for relay/fuse box under the glovebox
60
5
Primary fuse for central electrical unit in cargo area
60
6
Ventilation fan
40
7
8
9
Start relay
30
10
Internal diode
50
11
Support battery
70
12
Central electronic module (CEM) – reference voltage support battery; Charging point support battery
15
Fuses A1 and A2 are of the “MEGA Fuse” type and must only be replaced by a workshop. Fuses 1-11 are of the “Midi Fuse” type and must only be replaced by a workshop. Fuse 12 is of the “Mini Fuse” type.
FAQ
What are the cigar lighter (power outlet) fuses in the Volvo V60?
Fuse #22 (12V socket, tunnel console) in the fuse box “A” under the glove compartment, and fuse #7 (12V socket, cargo area) in the cargo compartment fuse box.
